Specification of Precision Dispense Piston Pump
| Specification | |||
| Product name | Piston pump | Power | 15W |
| item | value | motor | stepper motor |
| Warranty | 1 year | Precision (Repeatability) | 0.3%~0.7% (100% stroke) |
| Customized support | OEM | Valve head | single hole/double-hole with valve |
| Brand Name | RUNZE | ||
| Model Number | RP-01 | Maximum speed | 500rpm |
| Place of Origin | Jiangsu, China | Running time (per rated stroke) | 2.292s-1146s |
| Application | Micro Biology Detection, Medical Analysis | Resolution | 0.005mm/1.5707μl |
| Power Source | Electric | Wetted material | PC,ceramics,PTFE |
| Pressure | 0.075-0.2mpa | Connection | 1/4-28UNF female thread |
| Structure | Vacuum Pump | Operating temperature | 5~55℃ |
| Voltage | DC24V/1.5A | Volume | 6ml |
